Product Technical Specifications

80PLUS	Cetificate	Platinum
Form Factor	Power Supply	Intel ATX 12 V 3.1
Dimensions		165mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	140mm with ARGB LEDs
	Fan Control	Temperature control
	Fan Bearing	Hydraulic bearing
	Life Expectancy	50,000 hours
Cable Information	Modularity	Fully Modular
	Cable type	Embossed cables
Electrical Features	Operating Temperature	0-50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF	100,000 Hours (@ 25 °C, Excl. fan)
	AC Input	110-240V
	Protection	OPP / OVP/ UVP / OCP/ SCP / OTP / NLP / SIP / OLP / NLO
Safety Ceritificate	Safety and EMC	cTUVus, TUV, CB, CCC, EAC, CE
Environmental	Compliance	RoHS

RGB Modes Operation Instructions:

Key Function	RGB LED Status
Turn On, Entry last Mode	Keep the Save memory mode
Press RGB Switch	Select RGB light mode
Press and Hold in 3sec	OFF the RGB LED light
Press the Switch again	White light flashes once and Entry in o the last mode
Press Longer Don't release	Entry Self-Test mode(All led White Light
Release after Press longer	Exit Self-Test mode, Entry Last memory mode
ARGB SYNC	Access external ARGB HUB or 5V 3pin signal from motherboard
