GameMax VP 600S 600 Watts Power Supply 80+ Bronze - Black
|
Model name |
GAMEMAX VP 600 Standard Power Supply |
|
|
General |
ATX Version |
ATX 12V Ver. 2.31 |
|
PFC |
Active PFC |
|
|
Input Voltage |
200-240V |
|
|
Input Current |
5A |
|
|
Input Frequency |
50-60Hz |
|
|
Dimensions (L x W x H) |
140 x 150 x 86mm |
|
|
Efficiency |
≥ 85% @ Typical Load |
|
|
80 PLUS Rating |
Standard |
|
|
Protections |
OPP, OVP, UVP, OCP, OTP, SCP, SIP, OLP |
|
|
Safety Certificate |
CE / cTUVus / TUV / CB / RoHS |
|
|
Warranty |
5 Years |
|
|
Fan |
Size |
120mm |
|
Bearing |
HDB |
|
|
0dB Mode |
Yes |
|
|
Cables |
Type |
Embossed Flat |
|
Module |
Non Modular |
|
|
ATX 24 Pin |
MB 24(20+4) Pin x 1 (500mm) |
|
|
CPU 4+4 Pin |
CPU 8(4+4) Pin x 1 (650+150mm) |
|
|
PCI-e 12+4 Pin |
12V-2x6 (12+4) Pin x 1 (650mm) |
|
|
PCI-e 6+2 Pin |
PCIe 8(6+2) Pin x 1 (500+150mm) |
|
|
SATA |
SATA 4 Pin x 1 (400+150+150mm) |
|
